LX-PR-21B
Power source: 100-130VAC
220-240VAC
100-240VAC
Power frequency: 50/60Hz
Light-control: <20LUX
Rated Load: 800W Max.tungsten (100-130VAC)
100W Max. fluorescent (100-130VAC)
1200W Max.tungsten (220-240VAC)
200W Max. fluorescent (220-240VAC)
Detection range: 9m max (22℃)
Time setting: Min:8sec±3sec
Max:7min±2min(adjustable)
Detection angle: 140° 180°
Working temperature: -10~+40℃
Working humidity: <93%RH
Installation height: 1m~1.6m
Power consumption: 0.45W(static 0.1W)
Detection motion speed: 0.6~1.5m/s
